PRL Motorsports Performance Intercooler Charge Pipe Upgrade for 2021–2024 Acura TLX Type S (UB7)

Description

Fits all 2021 Acura TLX Type-S 3.0T

Fits all variant models including RHD, International Models, Etc.

INSTALL GUIDE

Important Notes:

• NO ECU CALIBRATION REQUIRED
• Compatible with Factory Intercooler outlet and PRL Motorsports Intercooler upgrade with 3″ outlet.

Technical Notes:

Our charge pipe upgrade kit utilizes a smooth flowing, larger diameter (3.00″ OD in comparison to the factory ~2.40″ ID hose) cold-side for increased airflow and factory diameter hot-side outlet to aid in turbocharger spool. 4-ply silicone couplers are used throughout our design for a couple of reasons:

1. Heat-soak reduction: Silicone hose offers extremely low thermal heat transfer properties, especially in comparison to steel or aluminum.

2. Strength and rigidity: The rubber hoses used from the factory are known to experience expansion, which worsens as boost is increased. In time, the rubber construct weakens, causing increased likeliness of a boost leak. Our high-temp, 4-ply silicone with handle the high temperatures of the turbocharger much better than the factory rubber hose(s).

3. Smooth airflow: Custom molded silicone allows us to offer much higher flowing bends than we could with metal tubing.

Kit Includes:

• (2) aluminum charge pipe, powdercoated wrinkle-black
• (1) 1/8″ NPT methanol injection bung
• (5) 4-ply silicone couplers
• (8) 304 stainless steel lined clamps
• All hardware needed for install
