Name: Fujitsubo AR-M+C Exhaust System for 2023–2024 Honda Civic Type R FL5
Brand: Fujitsubo
SKU: FUJ-270-52114
Availability: InStock

Description

Detailed Description

Product Name	A-RM+c
Item Number	270-52114

Authorized Number	JQR60234102 K20Ct
JAN CODE	4944997253147
Application	FL5 Civic Type R (Civic) Body model: 6BA-FL5 Engine model: K20C Year: R4.9~ (2022.9~)
Special Note
Remarks	Body: titanium, tail: carbon. *When using this product, the genuine exhaust electronic control valve cannot be used. Genuine exhaust valve canceller is included. Proximity exhaust noise was measured at 3500 rpm since the specified rotation speed was not reached.

Type	Titanium + carbon model
Tailtip Style	f118 round slash (carbon W)
Pipe Diameter	f70.0-f60.5
Fitting Parts	• 080-37001 Plate Gasket×1 [Click here to order] • 080-37601 Plate Gasket×1 [Click here to order] •M10×20 Flange bolt/flange nut set×2 •Slit clamp installation kit SLIT -HC70×2 •ARM+c dedicated split bracket [L]×1 •ARM+c dedicated split bracket [R]×1 •M8 plate washer×4 •M8 nut (S45C)×4 •M8×25mm bolt (8T) ×4 •M8 spring washer ×4 •Valve canceller ×1 •Special carbon tail pipe set ×2

	Standard (STD)	FUJITSUBO
Intermediate acceleration (40km/h?80km/h, 2nd gear)	3.5 seconds	3.4 seconds
Peak Power	214kw(291.0ps)/6144rpm	218kw(296.5hp)/6465rpm
Peak Torque	418.5Nm (42.7kg?m) / 3215rpm	420.4Nm (42.9kg-m)/3565rpm
Weight	18.3kg	12.9kg
Idling Exhaust Noise	65dB	71dB
Close-range exhaust noise (4875 rpm)	83dB	89dB
2000rpm Exhaust Noise	70dB	81dB
3000rpm Exhaust Noise	76dB	78dB
1000rpm to 3000rpm Exhaust Noise	86dB	91dB

Measurement vehicle	6BA-FL5
Roof height	1410mm (vehicle inspection certificate 1400mm)
Measurement area	Intermediate Pipe
Axle distance etc.	970mm behind the front axle
Minimum ground clearance	144mm

*In-house test values. Data may vary depending on the vehicle and conditions used
